CARBIDE DRILLS

Jobber Length

JOBBER LENGTH DRILLS

INCH, LETTER, NUMBER AND METRIC

BENEFITS & FEATURES
• Manufactured from premium submicron grain carbide
• Precision ground carbide drills are designed for high feed rate and good chip evacuation
• 118 four facet point angle, right hand cut-right hand spiral
0

JOBBER LENGTH DRILLS

Fraction Size Letter/Wire Metric Decimal Equiv. Flute Length OAL Uncoated AlTiN
- 76 0.51 0.0200 1/4 1-1/4 30030 30032
- 75 0.53 0.0210 1/4 1-1/4 30034 30036
- 74 0.57 0.0225 1/4 1-1/4 30038 30040
- 73 0.61 0.0240 1/4 1-1/4 30042 30044
- 72 0.64 0.0250 5/16 1-1/4 30046 30048
- 71 0.66 0.0260 5/16 1-1/4 30050 30052
- 70 0.71 0.0280 5/16 1-1/4 30054 30056
- 69 0.74 0.0292 5/16 1-1/4 30058 30060
- 68 0.79 0.0310 5/16 1-1/4 30062 30063
1/32 - 0.80 0.0312 5/16 1-1/4 30066 30068
- - 0.80 0.0315 7.9mm 31mm 30067 30069
- 67 0.81 0.0320 5/16 1-1/4 30064 30065
- - 66 0.84 0.0330 5/16 1-1/4 30074 30076
DRILLS - - 64 0.90 0.0354 16mm 35mm 30081 30083
1-3/8
0.89
5/8
0.0350
65
30080
30078
-
30082
0.91
30084
1-3/8
5/8
0.0360
- 63 0.94 0.0370 5/8 1-3/8 30086 30088
- 62 0.97 0.0380 5/8 1-3/8 30090 30092
- 61 0.99 0.0390 5/8 1-3/8 30094 30096
- - 1.00 0.0393 16mm 38mm 30098 30100
- 60 1.02 0.0400 3/4 1-1/2 30102 30104
- 59 1.04 0.0410 3/4 1-1/2 30106 30108
- 58 1.07 0.0420 3/4 1-1/2 30110 30112
- 57 1.09 0.0430 3/4 1-1/2 30114 30116
- - 1.10 0.0433 19mm 38mm 30118 30120
- 56 1.18 0.0465 3/4 1-1/2 30122 30123
3/64 - 1.19 0.0469 3/4 1-1/2 30126 30128
- - 1.20 0.0472 19mm 38mm 30130 30131
- - 1.25 0.0492 19mm 38mm 30132 30133
- - 1.30 0.0512 19mm 38mm 30134 30136
- 55 1.32 0.0520 3/4 1-1/2 30138 30139
- 54 1.40 0.0550 3/4 1-1/2 30142 30143
- - 1.40 0.0551 19mm 38mm 30146 30147
- - 1.45 0.0571 19mm 38mm 30148 30149
- - 1.50 0.0591 19mm 38mm 30150 30152
- 53 1.51 0.0595 3/4 1-1/2 30154 30155
1/16 - 1.59 0.0625 3/4 1-1/2 30158 30159
- - 1.60 0.0630 19mm 38mm 30162 30164
