EMSC 5/16 2FDEWR Bright 3/8 x 3/4 x 3-1/2 W/Flats
EMSC 5/16 2FDEWR Bright 3/8 x 3/4 x 3-1/2 W/Flats
Made from premium solid carbide for durability and precision.
Features 2 flutes for effective chip evacuation in softer materials.
Weldon Regular Dual-End Milling with Secure Clamping
The MSC 2 Flute Double End WR (Weldon Regular) end mill is available in both square end and ball nose configurations for slotting, profiling, and 3D contouring applications. The 2-flute geometry promotes efficient chip evacuation and controlled cutting performance, especially in deeper slotting operations. The double-end design provides two usable cutting ends to maximize tool life, while the Weldon Regular shank ensures secure clamping and improved torque transmission in set-screw holders. Manufactured from solid carbide and offered in Bright, TiN, TiCN, AlTiN, and other advanced coatings, this tool adapts to varying materials and machining conditions.
- 2 flute double end WR (Weldon Regular) design
- Available in square end and ball nose geometries
- Efficient chip evacuation for slotting and profiling
- Weldon Regular shank for secure clamping and torque control
- Solid carbide construction for rigidity and durability
- Coating options: Bright, TiN, TiCN, AlTiN, and others
- Steel
- Stainless Steel
- Iron
- Slotting and side milling
- 3D contouring (Ball Nose)
- CNC production machining
Piece Count: 1
Material: Solid Carbide
Tool Type: 2-Flute Double End Weldon
End Style: Square End
Cut Diameter (in): 46158
LOC (in): 0.75
Shank Diameter (in): 46158
OAL (in): 3.5
Coating: Uncoated, Bright
Uncoated.
