4 Flute | Imperial | End Mill

CLICK HERE for Product Matrix



4 Flute | Imperial (in) | End Mill

Cut Dia Shank Dia LOC OAL Square Uncoated Square AlTiN Coated Ball Uncoated Ball AlTiN Coated
1/64 1/8 1/32 1-1/2 22004 22012 23006 23014
1/32 1/8 1/16 1-1/2 22016 22024 23015 23017
1/32 1/8 1/8 1-1/2 22028 22036 23018 23026
3/64 1/8 3/32 1-1/2 22040 22048 23030 23038
3/64 1/8 1/8 1-1/2 22052 22060 23042 23050
1/16 1/8 1/8 1-1/2 22064 22072 23054 23062
1/16 1/8 3/16 1-1/2 22076 22084 23066 23074
5/64 1/8 3/16 1-1/2 22086 22088 23078 23086
5/64 1/8 1/4 1-1/2 22090 22096 23090 23098
3/32 1/8 3/16 1-1/2 22100 22108 23102 23110
3/32 1/8 3/8 1-1/2 22112 22120 23114 23122
7/64 1/8 7/32 1-1/2 22121 22123 23126 23134
7/64 1/8 3/8 1-1/2 22124 22132 23138 23146
1/8 1/8 1/4 1-1/2 22136 22144 23150 23158
1/8 1/8 1/2 1-1/2 22148 22156 23162 23170
1/8 1/8 3/4 2-1/4 22160 22168 23174 23182
1/8 1/8 1 3 22172 22180 23186 23194
1/8 1/8 1-1/8 4 22184 22192 23196 23200
1/8 1/8 1-1/2 4 22181 22182 - -
9/64 3/16 9/32 2 22193 22195 23210 23218
9/64 3/16 9/16 2 22196 22204 23222 23230
5/32 3/16 5/16 2 22208 22216 23234 23242
5/32 3/16 9/16 2 22220 22228 23246 23254
11/64 3/16 3/8 2 22241 22243 23255 23257
11/64 3/16 5/8 2 22232 22240 23258 23266
3/16 3/16 3/8 2 22244 22252 23270 23278
3/16 3/16 5/8 2 22256 22264 23282 23290
3/16 3/16 3/4 2-1/2 22268 22276 23294 23302
3/16 3/16 1-1/8 3 22280 22288 23306 23314
3/16 3/16 1-1/2 4 22292 22300 23315 23317
3/16 3/16 1-1/2 6 22304 22312 23319 23321
13/64 1/4 5/8 2-1/2 22316 22324 23318 23326
7/32 1/4 7/16 2 22328 22336 23330 23338
7/32 1/4 5/8 2-1/2 22340 22348 23342 23350
Cut Dia Shank Dia LOC OAL Square Uncoated Square AlTiN Coated Ball Uncoated Ball AlTiN Coated
15/64 1/4 3/4 2-1/2 22352 22360 23354 23362
1/4 1/4 1/2 2 22364 22372 23366 23374
1/4 1/4 3/4 2-1/2 22376 22384 23378 23386
1/4 1/4 1-1/8 3 22388 22396 23390 23398
1/4 1/4 1-1/2 4 22400 22408 23402 23410
1/4 1/4 1-1/2 6 22412 22420 23414 23422
1/4 1/4 2-1/2 6 22424 22432 23424 23427
17/64 5/16 3/4 2-1/2 22436 22444 23426 23434
9/32 5/16 3/4 2-1/2 22448 22456 23438 23446
19/64 5/16 13/16 2-1/2 22460 22468 23450 23458
5/16 5/16 1/2 2 22472 22480 23462 23470
5/16 5/16 13/16 2-1/2 22484 22492 23474 23482
5/16 5/16 1-1/8 3 22496 22504 23486 23494
5/16 5/16 1-1/2 6 22502 23492 23508 23511
5/16 5/16 1-5/8 4 22508 22516 23498 23506
5/16 5/16 2-1/2 6 22520 22528 23499 23517
21/64 3/8 1 2-1/2 22530 23507 23400 23519
11/32 3/8 1 2-1/2 22532 22540 23510 23518
23/64 3/8 1 2-1/2 22538 23512 23515 23520
3/8 3/8 1/2 2 22544 22552 23522 23530
3/8 3/8 1 2-1/2 22556 22564 23534 23542
3/8 3/8 1-1/8 3 22568 22576 23546 23554
3/8 3/8 1-1/2 6 22592 22600 23574 23578
3/8 3/8 1-3/4 4 22580 22588 23568 23572
3/8 3/8 2-1/2 6 22604 22612 23555 23557
25/64 7/16 1 2-3/4 22613 23560 23563 23565
13/32 7/16 1 2-3/4 22616 22624 23558 23566
27/64 7/16 1 2-3/4 22618 23567 23569 23571
7/16 7/16 5/8 2-1/2 22628 22636 23579 23581
7/16 7/16 1 2-3/4 22640 22648 23582 23590
7/16 7/16 2 4 22652 22660 23594 23602
7/16 7/16 3 6 22664 22672 23606 23614
29/64 1/2 1 3 22666 23608 23615 23623
15/32 1/2 1 3 22673 22675 23619 23621
Cut Dia Shank Dia LOC OAL Square Uncoated Square AlTiN Coated Ball Uncoated Ball AlTiN Coated
31/64 1/2 1 3 22687 23617 23627 23629
1/2 1/2 5/8 2-1/2 22676 22684 23618 23626
1/2 1/2 1 3 22688 22696 23630 23638
1/2 1/2 1-1/4 3 22697 23632 23639 23641
1/2 1/2 1-1/2 4 22698 23648 23643 23645
1/2 1/2 1-1/2 6 22724 22732 23666 23674
1/2 1/2 2 4 22700 22708 23642 23650
1/2 1/2 3 6 22712 22720 23654 23662
1/2 1/2 4 7 22736 22744 23678 23686
33/64 9/16 1-1/4 3-1/2 22750 23680 23691 23693
17/32 9/16 1-1/4 3-1/2 22754 23683 23695 23697
9/16 9/16 1-1/8 3-1/2 22760 22768 23690 23698
5/8 5/8 3/4 3 22772 22780 23702 23710
5/8 5/8 1-1/4 3-1/2 22784 22792 23714 23722
5/8 5/8 2-1/4 5 22796 22804 23726 23734
5/8 5/8 3 6 22808 22816 23738 23746
5/8 5/8 4 7 22820 22828 23750 23758
21/32 3/4 1-1/2 4 22830 22833 - -
11/16 3/4 1-3/8 4 22832 22840 23762 23770
3/4 3/4 1 3 22844 22852 23774 23782
3/4 3/4 1-1/2 4 22856 22864 23786 23794
3/4 3/4 2-1/4 5 22858 22866 23788 23796
3/4 3/4 3 6 22868 22876 23798 23806
3/4 3/4 3 6 22880 22888 23810 23818
3/4 3/4 4 7 22892 22900 23819 23821
3/4 3/4 5 8 22901 22903 23822 23830
7/8 7/8 1-1/2 4 22904 22912 23834 23842
1 1 1-1/2 4 22916 22924 23846 23854
1 1 - - 22928 22936 23858 23866
1 1 3 6 22940 22948 23870 23878
1 1 4 7 22952 22960 23880 23884
1 1 4 8 22964 22972 23886 23890
